Processing Channels with Pre-Outs: 9.4 Channel

• Discrete Power Amplifier Yes

• Power Transformer: Toroidal / EIEI

• Current Feedback Topology Yes

• Hyper Dynamic Amplifier Modules (HDAM) Yes (SA2)

• Pure Direct Yes

• Pure Direct Yes

• Gold Plated RCA Terminals Yes

• Clock Jitter Reducer Yes

• AudysseyMultEQ XT32

• Audyssey Dynamic EQ / Dynamic Volume Yes / Yes

• Subwoofer Mode: Standard / Directional Yes / Yes

• Dirac Live upgradability Yes

• Compressed Audio Enhancer: MDAX2 Yes

• HEOS Multi-Room and Streaming Yes

• Bluetooth Re-transmit for Bluetooth headphones Yes

• Volume control for Bluetooth transmitter Yes

• Network Audio Sharing Yes

• Lossy formats: MP3 / WMA / AAC Yes / Yes / Yes

• Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes

• DSD Audio Streaming Yes (2.8/5.6MHz)

• FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes

• Gapless Playback Yes (FLAC, WAV, ALAC, DSD)

• AirPlay Audio Streaming Yes (AirPlay2)

• Internet Radio Yes (TuneIn)

• Spotify* Connect Yes

• Tidal* Connect Yes

• Qobuz* Connect Yes

• Pandora / SiriusXM Yes / Yes

• Other Streaming Services, Amazon Music HD/TIDAL/Deezer/iHeart Radio/SoundCloud/Mood Mix

• Roon Ready Yes

• Compatible with remote app for smartphones Marantz AVR Remote / HEOS

• Compatible with remote app for tabletsAndroid / iOS / Amazon Kindle

• Wi-Fi / Bluetooth / Ethernet Ports Yes / Yes / Yes

• HDMI Inputs: Back / Front 6 / 0

• HDCP2.3 support Yes

• HDMI Outputs: Main / Zone2 / 1

• HDMI to HDMI scaling1080P/4K to 8K

• HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB Yes / Yes

• 8K/60Hz AB / 4K/120Hz AB Pass-through In/Out6 / 2 (up to 40Gbps)

• Enhanced ARC / ARC Yes / Yes

• HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR Yes / Yes / Yes / Yes / Yes

• ALLM (Auto Low Latency Mode) Pass-through for gaming Yes

• Variable Refresh Rate / Quick Flame Transport / Quick Media Switching Yes / Yes / No

• AMD FreeSync compatible Yes (HDMI 4-6)

• 3D Signal Pass-Through / HDMI Pass-Through in Standby Mode Yes / Yes

• Picture Adjust / Noise ReductionNo / No

• CEC / DSD Audio Capability / Auto LipSync Yes / Yes / Yes

• HEOS Multi-Room Integrated Yes

• HEOS Link Compatibility: IR/ IP Yes / Yes

• Multi-Room zones 2

• Zone Audio Source: HDMI Opt, Coax / Network, USB Analog Yes (2ch) Yes

• Zone Audio Output: Speaker / Preout Yes / Yes

• Zone HDMI Output from HDMI Source Yes

• IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes

• IR Flasher In / Marantz Remote Bus Yes / Yes

• DC Trigger Output1

• HDMI Diagnostics Yes

• Auto Speaker Setup by Microphone Audyssey MultEQ XT32 Dirac Live (upgrade)

• Front Display Porthole OLED

• Graphic User Interface – GUIModern HD GUI

• ISF Certification No

• GUI Languages 3

• Setup Assistant / Smart Select Yes / Yes

• Firmware Update by Network / USB Yes / Yes

• Variable Cross Over / Optimized Bass Redirection / Bass Sync Yes / Yes / Yes

• ECO Mode / Auto Power Off / Sleep Timer Yes / Yes / Yes

• HDMI In / Out6 / 3

• Multi-Room Video Out: Video / HDMINo / Yes

• Analog In / Out5 / 0

• Phono (MM) In Yes

• Digital In: Optical / Coaxial2 / 2

• Multi-Room Out: analog / digital1 / 0

• Multichannel Pre-Out Yes (11.4)

• Subwoofer Out4 (independent)

• Speaker Terminal: Gold Plated Screw / Regular Screw Yes / No

• Number of Speaker Terminals 11

• Speaker A / Bass ignable

• Bi-Amp Drive ass ignable

• Multi-Room Speaker Terminal ass ignable

• Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / No / Yes

• USB Audio / Made for iPod / Made for iPhone Yes / No / No

• USB Power supply on rear panel Yes

• AM/FM Tuner Yes

• Number of Power Amps 9

• Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) 110W

• Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 150W
