Sony ZRD-2 Crystal Micro-LED HDR TV

Price available by email or phone 914.723.3344 & is based on the screen size


Crystal LED is a modular technology, enabling it to be installed in virtually any desired size and resolution to accommodate consumers’ needs and residential space availability. Sample residential configurations include:

Full HD Size (18 Units) 4K Size (72 Units) 8K Size (288 Units) 16K Size (576 Units)
~110-inch Diagonal ~220-inch Diagonal ~440-inch Diagonal ~790-inch Diagonal
~8ft (W) x 4ft (H) ~16ft (W) x 9ft (H) ~32ft (W) x 18ft (H) ~63ft (W) x 18ft (H)

Crystal LED delivers over a million-to-one contrast ratio, the most accurate light levels, low heat emission and a picture quality that is absolutely breathtaking. By offering the display in modular configurations, consumers now have an exciting new option for the transition from home projection systems and large-screen TVs.

Crystal LED for home installation is available through a select group of specially trained and certified Sony dealers. The product is supported by Sony’s award-winning technical support team with additional design support resources, installation and maintenance on end-users’ applications provided by Sony Electronics, which will also offer custom installer Crystal LED service training, enabling them to remotely monitor and support displays after installation.

Sony’s Crystal LED direct view display system uses ultra-fine micro-LED measuring 0.003 mm² – half the width of a human hair – which are 100 times smaller than traditional LEDs. The display recently received a prestigious 2019 Display Industry Award for “Display of the Year” from the Society of Information Display, recognizing Crystal LED’s unprecedented visual experience. The technology delivers crisp, blur-free moving images with high frame rate up to 120p for razor-sharp motion rendition that is far beyond the reach of conventional video.

Additional technical highlights:

  • HDR with high brightness (1,000 nits)

  • 10-bit grayscale

  • Precise color reproduction

  • Extraordinary color gamut – 140 percent of sRGB

  • High frame rates up to 120p

  • Nearly 180-degree viewing angle

  • Spectacular 3D

  • Non-standard aspect ratios

  • 99 percent black surface area for delivering high contrast and high resolution

Value Electronics

Sony ZRD Crystal LED
pdf data sheet brochure
pdf cut sheet w/dimensions
Email us with questions

3 yrs Interest Free Financing w/purchase of any size ZRD

Delivered and installed by Sony Crystal LED technicians

Pictured left ZRCT-200

Control up to 72 ZRD-2 Crystal LED Display Units to create super-sized LED video walls, any size/scale.

The rack-mounting ZRCT-200 controls up to 72 ZRD-2 Display Units that can be seamlessly ‘tiled’ to create super-size LED video walls of virtually any dimensions or aspect ratio with Sony’s Crystal LED Technology.

Input terminals on the rear of the controller are provided as HDMI (2.0 × 2) and DisplayPort (DP1.2 x 2) for connection to a video source. A dedicated USB port on the controller’s front panel is provided for maintenance.

The ZRCT-200 is intended for operation with the ZRD-1 / ZRD-2 Display Unit (available separately) and the complete system is managed via Display Control Software application for Windows PC.

All Crystal LED products are made in Japan. Crystal LED products are compliant with the Trade Agreements Act and accordingly, may be purchased by the United States Government.
