Description

JVC DLA-NZ9 supports 8K HDR signal input, 8K60p/4K120p

Input & output ports & heat dissipation vents & adjustable feet

Key Features and Specifications:

• Light source: BLU-Escent laser.

• Display resolution: 8192 x 4320 (with 8K/e-shiftX).

• Input connectors: HDMI x 2 (48 Gbps/HDCP 2.3).

• Output and control connectors: RS-232C (D-sub 9pin) x 1, LAN (RJ-45) x 1, Trigger x 1 (Mini jack), 3D Sync x 1 (Mini-DIN 3pin).

• 3D formats: Frame Packing, Side-by-Side (Half), and Top & Bottom.

• JVC proprietary 8K/e-shiftX technology w/4-direction shift reproduces 8K-quality image .69″ 4K D-ILA 4096 x 2160 device x3.

• 18-element, 16-group all-glass 100mm diameter high-quality lens.

• Ultra-High Contrast Optics w/BLU-Escent laser light source contributes for optical brightness of 3,000 lumens & longevity of 20,000 hrs.

• Multiple Pixel Control image processor accurately renders all images closer to the original.

• Infinity:1 Dynamic Contrast Ratio; 100,000:1 Native Contrast Ratio.

• Cinema Filter (DCI-P3) creates saturated, beautiful images that come to life.

• Compatible with the two dynamic tone mappings of HDR10+ content & Frame Adapt HDR w/Theatre Optimizer*, the projector expresses HDR/HDR10+ content at optimum brightness & darkness in each scene as the creator intended.

• The projector automatically reproduces HDR & HDR10+ content based on the metadata for each scene.

• Frame Adapt HDR w/Theatre Optimizer performs tone mapping according to the input signal of the content as well as the installation environment.

• Installation mode w/10 memories centrally manage 9 settings to enjoy video best suited for each environment.

• Eight settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on/off, Screen Setting, Installation Style, Keystone & Aspect; stored installation modes for various environments can be called up.

• Compensation accuracy of Clear Motion Drive improved in the periphery of objects. Added with Motion Enhance technology, the projector can reproduce much smoother moving 4K images (function disabled when inputting 4K120p signals).

• Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles.

• Color Management System with 6-axis Matrix.

• Auto-Calibration Function using an optical sensor** is capable of optimizing essential elements in the image, including color balance, gamma characteristics, color space and color tracking.

• ISF C3 (Certified Calibration) mode*** to reproduce excellent picture quality optimized for specific environments.

• Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter.

• Warranty: 3 Years for all parts and labor.

*Theater Optimizer Can Be Activated Only When The Projectors Picture Mode As Set To Frame Adapt HDR. **Exclusive JVC software & Optical Sensor Are Required. ***Professional Calibration To Desired Screen Is Available By Trained Dealers, Which We Are With The Top Professional Projector & TV Calibrators Available Nationwide In The USA.

We accept all major credit cards & offer 1 year financing

---

• FREE firmware update was released on November 30^th for all current Procision series models DLANP5, DLANZ7, DLANZ8, and DLANZ9.  Key updates in this firmware include:

  • Second Generation Frame Adapt provides improved Dynamic Tone Mapping for HDR images with high peak white information in the image.

  • The laser light source adjustment can be finely adjusted according to the environment and user preference.

  • USB backup function can be used to save and rewrite all user OSD settings at one time.

• The new firmware can be downloaded from JVC’s website at Support Information & Download | JVC

---
